Small Castings Shot Blasting Machine
- 产品详情
With KEEJOO brand the high quality Small Castings Shot Blasting Machine is designed to remove rust, scale and burrs from the surface of castings and forgings that are prone to rolling off and not easily damaged by collision. The protective measures are excellent, the shot blasting performance is high, and the circulation system is reasonable. Even for the strengthening of workpieces that are difficult to clean, a satisfactory cleaning effect can be achieved.
Technical data
Parameter Unit 3GN 8GN 8GN-5R 15GN Productivity t/h 0.6-1.2 2-4 2-3 3-5 Feeding Amount kg 220 650 650 1000 Max Weight of SingleWorkpiece kg 12 32 32 55 Diameter of end disk mm 650 1000 1000 1150 Effective volume m3 0.15 0.3 0.3 0.5 Abrasive flowrate Kg/min 180 270 270 300 Ventilation capacity m3 2300 3500 3500 5000 Total power kw 13.1 23.2 27.4 39.4 Function
Our small casting Tumblast shot blasting machine has below functions :
1.Surface treatment: Small casting Tumblast shot blasting machine can remove the oxide scale, rust and residues on the surface of cast aluminum parts, while reducing the internal stress of the workpiece and enhancing its fatigue strength.
2.Strengthening effect: It enhances the surface hardness of the workpiece through shot impact and is suitable for precision castings.Structural features
The essence of the structural design of the small casting Tumblast shot blasting machine lies in: centering on "efficient separation" and "automated circulation", through a compact chamber, high-performance shot blasting machine, full curtain separator and automatic loading and unloading, the small casting Tumblast shot blasting machine realizes the automated surface treatment of a large number of small castings.
Wear-resistant tumblast: Wear-resistant rubber tracks are adopted to reduce workpiece collision damage and noise.
Sealed design: The chamber body is made of Mn13 guard plates, reducing maintenance costs by approximately 60%.
Dust removal system: Equipped with bag-type dust collectors, dust emissions comply with environmental protection standards.Classification
Item NO.: 3GN Tumblast Type Shot Blasting Machine With Manual Door
Item NO.: 8GN tumblast type shot blasting machine with manual door
Item NO.: 8GN tumblast type shot blasting machine with Pneumatic door
Item NO.: 8GN-5R tumblast type shot blasting machine with Automatic Feeding And Vibrator Conveyor
Item NO.: 15GN Steel tumblast shot blasting machine with Automatic Feeding And Vibrator Conveyor
Item NO.: 28GN Steel belt shot blasting machine with Automatic Feeding And Vibrator Conveyor
